Khaleed Stainless a trusted name in the metal industry and stands tall as a major manufacturer and supplier of premium Stainless Steel Tee Fittings in Riyadh, Saudi Arabia. It is available with exceptional strength, high corrosion resistance and durability. Stainless Steel Tee Fittings are perfect installation accessories for a number of industrial applications. Including chemical processing, plumbing systems and food processing. Quality matched with customer satisfaction is our moto, ensuring we meet the top industry standards. Our Fittings in Stainless Steel are offered in different grades and sizes to meet the requirements of various projects. Thus making best and reliable delivery of solutions adapted to your industrial requirement.
Stainless Steel Tees are generally made from grades 304, 304L, 316, 316L, and 321, which include chromium (16–20%), nickel (8–12%), and molybdenum (2–3%) in select grades to enhance corrosion and pitting resistance. They exhibit tensile strength ranging from 515–620 MPa and yield strength between 205–290 MPa, maintaining excellent toughness even at elevated temperatures. These fittings are resistant to oxidation, stress, and pressure while ensuring superior dimensional stability. Their mechanical strength, ductility, and hardness make them perfect for demanding applications, guaranteeing leak-proof and durable pipeline connections across various industries.
| Grades | 201, 202, 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Size | ½”NB to 48″NB in |
| Schedule | Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| SS | 304 | 304N | 304LN |
|---|---|---|---|
| Ni | 8 – 11 | 8 – 11 | 8 – 11 |
| Fe | Balance | ||
| Cr | 18 – 20 | 18 – 20 | 18 – 20 |
| C | 0.08 max | 0.08 max | 0.035 max |
| Si | 0.75 max | 0.75 max | 0.75 max |
| Mn | 2 max | 2 max | 2 max |
| P | 0.040 max | 0.040 max | 0.040 max |
| S | 0.030 max | 0.030 max | 0.030 max |
| N | 0.10 – 0.16 | 0.10 – 0.16 | |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Contact us to get a quick quote for your requirement.
We ensure that every Stainless Steel Tee Fitting undergoes rigorous testing before leaving our premises, maintaining the highest quality standards at all times. Hardness Testing, Chemical Analysis (Spectro Analysis), Positive Material Identification (PMI Testing), Flattening Test, Micro and Macro Testing, Pitting Resistance Test, Flaring Test and Intergranular Corrosion (IGC) Testing are just some of the tests performed on Stainless Steel Tee Fittings before shipping.
Yes, stainless steel tees are fully recyclable. They can be melted down and reused without losing their properties, making them an environmentally friendly and sustainable material choice.
Common grades of stainless steel used in tee fittings manufacturing include 304, 304L, 316, 316L, and 321. These grades offer excellent corrosion resistance, durability, and suitability for various applications.
Yes, stainless steel tee fittings are ideal for hygienic and sanitary applications due to their corrosion resistance, smooth surfaces, and ease of cleaning, meeting strict industry standards.
Key considerations for selecting stainless steel tee fittings include material grade, corrosion resistance, pressure and temperature requirements, compatibility with media, application standards, and cost-effectiveness for long-term use.
Stainless Steel Tees find extensive use in industries that require strong pipeline connections and effective fluid flow management. In oil & gas and petrochemical facilities, they play a crucial role in splitting or merging process lines. Power generation plants utilize them in boilers, condensers, and cooling systems. The chemical and pharmaceutical sectors depend on them for corrosion-resistant piping networks. Additionally, they are employed in water treatment plants, food processing, and marine applications. Their versatility, durability, and ease of installation make stainless steel tees indispensable in today’s industrial landscape.
