Khaleed Stainless is a reputable manufacturer and supplier of high-quality stainless steel structural products based in Riyadh, Saudi Arabia. They focus on Stainless Steel 316/316L Angles, which are celebrated for their outstanding corrosion resistance, strength, and versatility. Crafted for tough industrial settings, these angles are made with precision to comply with international standards. Khaleed Stainless caters to essential sectors like construction, marine, oil and gas, and chemical processing, delivering reliable structural components that stand up to challenging conditions, including exposure to chemicals, moisture, and high temperatures.
The Stainless Steel 316/316L Angles from Khaleed Stainless contain 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, which boosts their resistance to pitting and crevice corrosion, especially in marine and chloride-rich environments. The 316L version has lower carbon content, enhancing weldability and minimizing the risk of corrosion post-welding. These angles boast a tensile strength of around 485 MPa and a yield strength of 170 MPa, along with impressive ductility and toughness. Their chemical and mechanical properties make them perfect for durable structural applications in aggressive environments.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
We conducts a strict quality test and obtains certifications to guarantee the best Stainless Steel 316/316L Angles in terms of strength, corrosion resistance, and accuracy. Each product batch is certified for compliance with international standards and offers clients full assurance in terms of reliability, performance, and conformity to industrial needs for a variety of uses.
Stainless Steel 316/316L angles are L-shaped structural components known for their excellent corrosion resistance, strength, and durability. They are used in marine, chemical, and high-temperature applications for support and reinforcement.
Stainless Steel 316/316L equal angles have two legs of the same length, forming a 90-degree angle. They offer high strength and corrosion resistance, ideal for structural support in demanding environments.
Stainless Steel 316/316L unequal angles have legs of different lengths, creating a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L L angles are L-shaped structural components offering high strength, durability, and superior corrosion resistance. They are used for framing and support in marine, chemical, and high-temperature environments.
SS 316/316L T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are ideal for structural and framework applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L corner angles are L-shaped sections designed for reinforcing and joining corners. They offer high strength, durability, and excellent corrosion resistance, making them suitable for construction and architectural applications.
Khaleed Stainless’s Stainless Steel 316/316L Angles find use in a variety of structural and fabrication applications. They are particularly suited for bracing, framing, and support structures across industries such as construction, shipbuilding, chemical processing, and food production. These angles are especially prized in settings where exposure to corrosive elements is frequent. Their strength and corrosion resistance also make them ideal for outdoor frameworks, equipment supports, and architectural features that require both functionality and aesthetic longevity. The 316L variant is particularly preferred for welded structures where corrosion resistance is crucial.
