Home > Stainless Steel 304/304L Angles
Khaleed Stainless stands out as a top manufacturer and supplier of high-quality Stainless Steel 304/304L Angles in Riyadh, Saudi Arabia. We provide robust and corrosion-resistant structural solutions tailored for a variety of industries. SS 304 and 304L are austenitic stainless steels celebrated for their remarkable corrosion resistance, strength, and formability. The low-carbon variant, SS 304L, guarantees superior weldability while reducing carbide precipitation during fabrication. Our angles are meticulously engineered to meet international standards, ensuring consistent dimensions, a smooth surface finish, and outstanding mechanical properties. These stainless steel angles are perfect for construction, architecture, automotive, marine, and chemical sectors, offering reliability, durability, and a long service life.
Stainless Steel 304/304L Angles are composed of 18–20% chromium and 8–12% nickel, with carbon content capped at ≤0.08% for 304L and ≤0.10% for 304. They also include ≤2% manganese, ≤1% silicon, ≤0.045% phosphorus, and ≤0.03% sulfur. With a tensile strength of about 515 MPa, yield strength of 205 MPa, elongation of 40%, and Brinell hardness ranging from 170 to 180 HB, both grades exhibit excellent toughness, corrosion resistance, and formability. The low-carbon 304L variant enhances weldability and minimizes the risk of sensitization in welded structures, making these angles ideal for high-performance structural applications.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
At Khaleed Stainless, all stainless steel 304/304L faces are rigorously tested to ensure quality and reliability. Certified to international standards, our products come with material test reports (MTR), third-party inspection certificates, and compliance with ASTM/ASME specifications. This ensures optimal performance, security and customer reliability in any application.
Stainless Steel 304/304L angles are L-shaped structural sections offering high strength, corrosion resistance, and durability. They are used in construction, manufacturing, and architectural applications for support and reinforcement.
Stainless Steel 304/304L equal angles feature two legs of the same length, forming a 90-degree angle. They provide strong, durable support and are widely used in construction and structural applications.
Stainless Steel 304/304L unequal angles have legs of different lengths, forming a 90-degree angle. They offer versatile support and reinforcement in construction and industrial applications, with high strength and corrosion resistance.
Stainless Steel 304/304L L angles are L-shaped structural components used for framing and support. They provide high strength, durability, and corrosion resistance, suitable for construction, manufacturing, and architectural applications.
SS 304/304L T-bar angles are stainless steel sections with a T-shaped profile. They provide robust support and stability for structural and framework applications, offering high strength, durability, and corrosion resistance.
Stainless Steel 304/304L corner angles are L-shaped sections designed to reinforce and join corners. They offer high strength, durability, and corrosion resistance, ideal for construction and architectural applications.
Stainless Steel 304/304L Angles find extensive use in structural frameworks, building construction, industrial machinery, storage racks, and architectural projects. Their exceptional corrosion resistance and strength make them suitable for marine, chemical, petrochemical, and food processing industries. These angles are perfect for creating supports, braces, frames, and load-bearing structures that demand durability and stability. Engineers and fabricators often choose SS 304/304L for their reliability and performance in various applications.
